Engineering Plastics for Water Treatment & Desalination Systems

Why Plastics Displace Stainless Steel

Stainless steel is not invincible in water systems. Chlorides pit even 316L, and stress corrosion cracking takes down pump shafts in high-chloride service. Plastics eliminate both failure modes, and they add benefits the metal cannot match: thermal insulation that reduces heat loss, low weight that simplifies installation, and no galvanic coupling when dissimilar metals would otherwise meet. In membrane systems, PVDF and PSU housings also avoid the metal-ion leaching that can foul membranes over time — a purity advantage as much as a durability one.

Specification Notes

· Confirm the grade’s compliance for potable water contact where applicable

· Check pressure rating at maximum operating temperature, not at ambient

· Verify chemical compatibility against the actual cleaning regime, not just the process fluid

· For desalination, specify materials rated for continuous chloride exposure

· Ask for batch traceability if the components sit in the potable water path

One specification detail that catches designers out: the pressure rating printed on a plastic component normally applies at ambient temperature, and allowable stress falls noticeably as temperature rises. A housing rated for 16 bar cold may be limited to 8 bar at 60°C. Water systems frequently combine both extremes — high-pressure hot cleaning cycles — so verify the rating at the worst-case combination rather than at either condition separately, and ask for test data if the supplier does not publish it.
